304 Stainless Steel Castor Wheels 125mm High Temperature Nylon Caster Wheels

500
MOQ
21.61
Price
304 Stainless Steel Castor Wheels 125mm  High Temperature Nylon Caster Wheels
Features Gallery Product Description Request A Quote
Features
Specifications
Wheel Diameter: 75/100/125 Mm
Tread Width: 32 Mm
Bearing Type: Double Ball Bearing
Plate Size: 65×94 Mm
Hole Spacing: 45×78mm / 45×71mm
Thread Size: M12 × 30 Mm
Load Capacity: 73/105/115 Kg Per Caster
Installation: Top-plate Mount
Wheel Material: High-Temperature Nylon
Name: High Temperature Nylon Caster Wheels
Highlight:

304 Stainless Steel Castor Wheels

,

Stainless Steel Castor Wheels 125mm

,

High Temperature Nylon Caster Wheels

Basic Infomation
Place of Origin: China
Brand Name: Dajin
Certification: Rosh/CE/IOS
Model Number: HTC-001
Payment & Shipping Terms
Packaging Details: 21X21X21 cm
Delivery Time: 25
Payment Terms: L/C,T/T
Product Description
Medium Duty 304 Stainless Steel High-Temperature Nylon Casters (73-115KG)

Features



1.High-Temperature Resistance: Hi-temp nylon wheels withstand temperatures from -40°C to +120°C, ideal for heat-exposed environments.

2.Stainless Steel Durability: 304-grade frame resists corrosion, acids, and frequent sanitization.

3.Precision Bearing System: Double ball bearings ensure smooth 360° rotation under load.

4.Optimized Dimensions:

  • Wheel diameters: 75/100/125mm
  • Low-profile installation heights: 105/130/158mm
  • Compact rotational radius: 70-110mm

5.Versatile Mounting:

  • 65×94mm plate with dual hole patterns (45×78mm or 45×71mm)
  • 8.5mm bolt holes for secure fastening

Function


These casters provide heat-resistant mobility for medium-duty equipment. The high-temperature nylon wheels maintain structural integrity in thermal environments, while the stainless steel frame ensures hygiene and corrosion resistance. The double ball bearings reduce rolling effort by 30% compared to single bearings, ideal for frequent repositioning.


Application



1.Platform trucks
2.Light institutional equipment
3.Display fixtures
4.Bread racks
5.Moving dollies



Technical Parameters



item
value
Model Name
Medium Duty 304 Stainless Steel High-Temperature Nylon Casters
Tread High-Temperature Nylon
Type
Plate Casters, Stem Casters, Bolt-Hole Casters, Side-Mount Casters
Style
Rigid, SWIVEL, Swivel & Rigid
Customized support
OEM, ODM, OBM
Place of Origin
China
Wheel Diameter 75/100/125 mm
Wheel Diameter 32 mm
Plate Size 45×78mm or 45×71mm
Thread Size M12*30 mm
Load Capacity
73/105/115 kg per caster
Hole Size
8.5 mm
