Attribute | Value |
---|---|
Wheel Material | Polyurethane (PU), Nylon, Rubber, Cast Iron |
Material | PA6 (core), TPR (tread), Metal (housing) |
Bolt Hole Diameter | Φ7mm, Φ9mm, Φ11mm |
Tread Width | 19/24/30/32mm |
Wheel Diameter | 40/50/62/70mm |
Application | Food & Beverage, Retail, Restaurants, Machinery |
Plate Size | 73×73 inches |
Plate Hole Spacing | 58×58 / 70×70 mm |
Temperature Range | –25°C to +85°C (typical for PA6/TPR) |
Height | 86/110 mm |
Enables stable and level placement of equipment or furniture, even on sloped or irregular floors. Adjustable height function allows for minor elevation changes, ensuring precise leveling. Supports heavy loads while maintaining mobility and stability.
Item | Wheel Diameter (mm) | Tread Width (mm) | Load Height (mm) | Adjustable Height (mm) | Plate Size (mm) | Hole Spacing (mm) | Load Capacity for 1pc (kgs) | Load Capacity for 4pc (kgs) |
---|---|---|---|---|---|---|---|---|
GD40A | 40 | 19.2 | 75 | 8 | 55×55×3 | 42×42 (Φ7) | 50 | 100 |
GD60A | 50 | 24 | 85 | 10 | 73×73×5 | 58×58 (Φ7) | 250 | 500 |
GD80A | 62 | 30.7 | 110 | 12 | 90×90×5 | 70×70 (Φ9) | 500 | 1000 |
GD100A | 75 | 32 | 120 | 12 | 95×95×5 | 70×70 (Φ11) | 750 | 1500 |
